Vivitek DU9800Z-BK Laser Projector - NO LENS

Part Number: DU9800Z-BK
Call for Pricing
Availability: Usually ships the same business day
Call 1-888-686-0551 for best price and to order!
Description
Specifications
Accessories
Reviews
Downloads
Vivitek DU9800Z-BK Laser Projector - NO LENS

Shine Bright with an SSL Laser Projector delivering 18,000 Lumens, Rich Connectivity, Edge-Blending, and Maintenance-Free Operating Time

Excellent Connectivity - The Vivitek DU9800Z provides the connections necessary for many diverse projection environments: HDMI (2), Component (YPbPr), Displayport, VGA input/output, 3D Sync Out, 3G SDI(HD-SDI) -In/Out, RS232, Wired Remote, HDBaseT/LAN and 12V Trigger (2).

Key Features
  • Bright 18,000 ANSI lumens with a native WUXGA (1,920 x 1,200) resolution for impeciablle colors and outstanding details
  • DLP DarkChip3 and BrilliantColor technologies for optimal black levels and vibrant colorful images
  • Sold state laser phosphor light source for reliable projection and performance
  • Environmentally friendly lamp-less design that is mercury-free and energy efficient
  • Almost maintenance-free with up to 20,000 hours of operating time
  • Advanced video processor for fluid video streaming and 10-bit programmable RGB color adjustments
  • Laser light source produces rich colors for an incredible cincematic like movie experience
  • Fine tune and optimize an image with advanced calibrations, including gamma and color management settings
  • Built-in hardware edge blending and warping functionality
  • Powered zoom, focus and lens shift (horizontal/vertical) for easy adjustment and positioning flexibility
  • Picture-in-Picture (PIP) for simultaneously image projection from two different active sources
  • Full suite of display connectivity inputs and outputs including: HDMI v1.4, DVI-D, Component (5 BNC) , VGA-In, 3G-SDI-In/Out, VGA-Out, HDBaseT
  • HDBaseT interface with support for distribution of digitalvideo content over standard CAT5e/6 LAN cable
  • Portrait mode projection allows the projector to be easily setup and installed in a 90° installation
  • 360° operation and projection design for set up in all angles
  • Instantaneous power-on & off, so no need for system pre-heating and postcooling
  • Airtight sealed engine and filter-less design for improved performance against fighting dust and fibers
  • Frame sequential and dual channel 3D supported
  • Complete range of motorized interchangeable lens in sizes from 0:84 to 7:01 (Optional)
  • Optimized system layout with high efficiency cooling system
  • Heavy duty steel chassis for extra strength and integrity
  • 24/7 continuous operation with no downtime
  • Network ready for integration and system administration via RJ45


Detailed Specifications
Resolution:WUXGA (1920 x 1200)
Display Device:0.96" Single Chip DLP
Brightness:18000 Lumens
Contrast Ratio:10000:1
Video Signals:NTSC, PAL, SECAM; Computer signals up to WUXGA (1920x1200)
Aspect Ratio:16:10
Number of Colors:Full Color
Lamp:Laser Light Engine
Typical Lamp Life:Up to 20,000 Hours
Lens:NO LENS
Throw Ratio:Depends on Lens; Lens not included
Image Size:Depends on Lens; Lens not included
Throw Distance:Depends on Lens; Lens not included
Keystone Correction:Vertical ±40°; Horizontal ±60°
Projection Methods:Table Top, Ceiling Mount, Portrait (Front or Rear)
Inputs:HDMI x 2
DVI x 1
VGA x 1
5BNC x 1
RJ45 x 1
RS232 x 1
3D Sync x 2
12-Volt Trigger x 1
Wired Remote In x 1
3G SDI In x 1
3G SDI Out x 1
Outputs:VGA x 1
Speaker:None
Audible Noise:43dB
Weight:105.8 lbs.
Dimensions:26.8" x 20.9" x 9.8"
Accessories:AC Power Cord, Remote Control w/Batteries, Lens Cap, Documentation Kit
Remote Control:Remote Control Included with Batteries
Mfg Warranty:Large Venue Laser Phosphor Warranty: 5 Year projector / 3 years or 10000 hours on the Laser Phosphor illumination source.(Whichever comes first)
Product Data Sheet: Product Data Sheet
