Panasonic PT-HTQ20G Projector - NO LENS

Redefine Immersive with Rec.2020 Color, 20,000 lm Brightness, and Detailed 4K Resolution - PT-HTQ20U

The Starling Tab Tension 3 delivers premium performance with a sleek, reliable, motorized design. Its tab tensioned CineWhite® screen ensures exceptional flatness for stunning clarity across a wide viewing angle, and the ISF Certified 1.1 gain surface supports 4K UHD and active 3D projection. A robust tubular motor ensures smooth operation, and adjustable mounting brackets make installation effortless. Every unit comes fully equipped with the SWIFT-RC1® control system and includes IR/RF remotes, a wall control box, and 12 volt trigger integration for seamless automation.

• 1. Immersive Visual Expression for Diverse Environments The PT-HTQ20 combines Rec.2020 color, 20,000 lm1 brightness, and 4K4 resolution to enhance visual realism with exceptional color expression. VIVID PRIME™ technology maintains smooth tonal gradation for Rec.709 content with reduced artifacts for comfortable viewing.
• Smooth 4K Images with Quad Pixel DriveRefined and improved over three generations of development, Quad Pixel Drive enhances perceived 4K image detail by applying high-speed pixel shifting in both the vertical and horizontal directions. Combined with 240 Hz signal processing, the system divides each frame into sub-frames and precisely aligns them on screen to create a denser, smoother image with reduced visible pixel structure. The result is exceptionally smooth, detailed 4K images, even at close viewing distances.
• Supports High-Speed 240 Hz Video The PT-HTQ20 supports 1080p/240 Hz video playback for smooth reproduction of fast motion with minimal blur with input-to-output latency of less than 6 ms. High-speed content can be displayed across multiple screens with edge blending enabled, ideal for eSports and other applications where fluid, low-latency motion reproduction is important.
• Improved 25,000:1 Dynamic Contrast Technology Dynamic Contrast technology has been enhanced to achieve a 25,000:1 contrast ratio. Advanced scene analysis enables more precise recognition of light and dark areas, improving overall contrast expression. The system analyzes content frame by frame and dynamically adjusts light output to match the requirements of each scene.
• Gradation Smoother 2 – Precise and Powerful Control Gradation Smoother 2 reduces banding noise in color gradients. The updated system expands adjustment from three to six correction levels, enabling finer control and more effective suppression of noise in challenging material. Users can select the appropriate level via the remote or disable the function when not required, minimizing the need for content re-editing.



• 2. Flexible Installation with Flagship Features Built-in 12G-SDI connectivity, an Intel® SDM standard-compatible SLOT7, Visual Software Suite8 support, and compatibility with existing D3LE-series lenses for 3-Chip DLP™ projectors streamline workflows and reduce TCO for rental companies and owner-operators.
• Compatible with D3LE-Series Lenses for Panasonic 3-Chip DLP™ Projectors The PT-HTQ20 is compatible with current-generation D3LE-series lenses used with most Panasonic 3-Chip DLP™ projectors, helping to maximize asset utilization and reduce the total cost of ownership. High-quality optics with Lens ID, Lens Memory, and Active Focus Optimizer (AFO) functions ensure precise setup and optimal image performance.



• Efficient Logistics and Shared Compatibility With compact body dimensions similar to the PT-RQ25K Series, the PT-HTQ20 can be carried by a crew of two, easing transport, storage, and deployment demands. Recessed side grips improve handling, while compatibility with existing PT-RQ25K Series frames, flight cases, and D3LE-series lenses helps streamline fleet upgrades and maximize return on existing assets.



• Operates on AC 100–120 V for Setup The PT-HTQ20 supports both AC 200–240 V power for full-brightness projection and AC 100–120 V for setup and calibration. Complete setup and image calibration using power from the consumer grid and avoid delays while high-voltage power is rolled out on site.
• 12G-SDI Input and Intel® SDM Standard-Compatible Slot The PT-HTQ20 equips a 12G-SDI input as standard, enabling stable transmission of high-bandwidth, high-resolution video content over long distances. An Intel® SDM standard-compatible SLOT integrates optional third-party or proprietary function boards such as our ET-SBFMP10 Media Processor, which simplifies complex multi-projector systems and reduces setup time for projection mapping and other large-scale installations.



• Flexible Black-Level Adjustment for Curved Screens Black-level adjustment on curved and irregular screens is now more precise. Up to 33 adjustable control points—the highest number on any Panasonic projector to date—allow black-level adjustment boundaries to be reshaped to follow warped blend edges, enabling accurate black-level matching across blended areas for more seamless multi-screen images.



• Improved Black-Level Uniformity Beyond the Display Area Independent black-level and geometric adjustment helps reduce black-level bumps beyond the display area. Black-level correction can be applied across the entire blend, including image overlaps beyond the display area, for smoother black-level transitions across blended images.
• Compatible with Visual Software Suite (VSS)
• Visual Software Suite is a free, Windows®-based platform that combines multiple functions into one intuitive graphical interface, enabling swift and efficient setup and onsite adjustments. Integrating and enhancing the capabilities of previously separate Panasonic software, it transforms your workflow into streamlined and cost-effective processes. For more information, please visit the VSS webpage.
• Automatic Black-Level Matching with VSS Visual Software Suite automatically matches black levels in overlapping areas of edge-blended horizontal and vertical images using an optional IDS or compatible Nikon camera, creating more seamless, uniform multi-screen images.
• Optional Media Processors to Simplify Multi-Projection The PT-HTQ20 works with Panasonic’s optional ET-FMP50 Series media processors to simplify multi-projection complexity. The processors, which comprise box-type and function board-type for the projector's Intel® SDM standard-compatible SLOT, feature automatic warping/blending and media playback capabilities.
• Check Settings and Status with Information Monitor A 2.4-inch OLED Information Monitor displays real-time operating status, including temperature, voltage, runtime, input signal, error codes, and projector posture with the newly added Angle Monitor function. Use the keypad to configure network settings, check system status, or update firmware while the projector is in standby, eliminating the need to project the OSD and streamlining setup and maintenance.
• Contrast Sync and Shutter Sync via LAN Enhanced multi-projector contrast and shutter sync is now supported over LAN only or, if preferred, conventional daisy-chain BNC connections. Reduce cabling requirements, lower system costs, and simplify installation without compromising on performance.
• Smart Projector Control App Integration Smart Projector Control app enables the control and adjustment of up to 64 projectors from a smartphone or tablet over wireless LAN. Access the projector menu via the Web Control UI and manage key functions including test pattern selection, lens setup, shift, zoom, and focus via the device camera, as well as shutter operation, brightness locking, and status monitoring.
• USB Control Connect: App Control Without Wireless LAN Avoid delays during projector setup when network infrastructure is not yet available on site. USB Control Connect enables use of the Smart Projector Control app via a USB connection, allowing installers to perform screen adjustments and configure settings directly from their mobile device. Improve setup efficiency and keep your project on schedule.
• NFC Function: Prep Without AC Power Prepare your projectors before power is available on site and reset them after use without on-screen menu projection. Using the Smart Projector Control app and NFC, installers can assign projector IDs, set IP addresses, and prepare units for network connection while unplugged. After the event, settings can be initialized to factory defaults prior to crating, streamlining teardown and ensuring projectors are ready for the next deployment.
• Pre-Show Video Checks with Remote Preview Remote Preview allows projectionists to verify input signals via video thumbnails before projection. Accessible via Multi Monitoring & Control Software or web browser, it works in Standby or with the mechanical shutter activated, helping identify issues in advance and reduce on-site errors when screen access is limited.
• Angle Monitor for Convenient, Resource-Friendly Adjustment The PT-HTQ20 features a built-in sensor that detects changes in the projector’s pitch and roll angles, which can be displayed in the settings menu, over a test pattern, or via the projector’s Information Monitor display. A single technician can view the information and adjust the projection angle without needing assistance from another team member.





• 3. High Reliability for Demanding ApplicationsEngineered for stable operation, the PT-HTQ20 combines an IP5X-conformant9 light source and optical engine, mechanical shutter, coated circuit boards10, and fail-safe technologies to deliver low-maintenance, reliable performance in demanding environments.
• Coated Circuit Boards for Enhanced Durability Selected circuit boards are treated with a proprietary coating that helps suppress corrosion caused by moisture and dust. This added layer of protection improves reliability in harsh environments. By reducing the impact of environmental factors on key components, the design supports stable, long-term operation in demanding conditions.
• Built-In Mechanical Shutter The PT-HTQ20 features an internal mechanical shutter. Designed for live event environments where laser lighting is often used, the shutter helps protect the DMD chip by blocking stray laser beams that may enter through the projection lens, reinforcing reliability in demanding production settings.
• Low-Maintenance, Dust-Resistant Design The PT-HTQ20’s optical engine and laser light source conform to the IP5X Dust Protected (IEC 60529) standard, eliminating the need for an air filter and reducing maintenance requirements. Sealed liquid-cooling system and refined airflow path help stabilize performance in demanding conditions. Reliability is proven through accelerated dust testing based on in-house standards, simulating environments with high levels of airborne particulates.
• Backup Input for Reliable Signal Redundancy Backup Input mode safeguards projection by enabling automatic failover between two identical signals. When the source outputs the same content to designated primary and backup inputs—either HDMI™ or SDI—the projector instantly switches to the backup if the main signal is lost, with no screen blanking. This reduces the chance of image display interruption and provides greater peace of mind in mission-critical environments.
• Failover Circuitry Minimizes Interruptions Multiple laser modules incorporate unique Failover Circuitry. If a single diode fails, only the affected series is bypassed rather than the entire module, as with some conventional designs. Projection continues uninterrupted with minimal loss of brightness, providing an added layer of reliability where continuous image display is critical.
• Reduced Operating NoiseTo reduce the chance of distraction and maintain audience immersion in quiet production environments, operating noise in NORMAL/ECO mode is limited to just 42 dB—significantly lower than PT-RQ25K Series in the same operating mode.

• Product Data Sheet
