Key Digital 4 Input Multi-format Switcher and USB 2.0 Wall Plate 100m HDBaseT Transmitter - KD-X4X1WUTx

Description

Features

Presentation Switching: 2 HDMI, 1 Display Port, and 1 USB-C source selection by push button or IP control
Installation: Fits in standard US 3-gang wall box or table and wall AV boxes
Rx Options: Native integration with KD-X100MRx black box HDBaseT Rx or KD-UPS52U Presentation Switcher. Future Rx options may be available
Video Conference USB Hub: USB Host + Device ports create connectivity hub for professional USB cameras and microphones, audio DSP, keyboard, mouse, or touchscreen display with connected computer
Ultra HD/4K: Supports up to 4096x2160 or 3840x2160 24/25/30/60hz at 4:4:4 (signals up to 18Gbps bandwidth)
Auto-Sensing: Automatic selection of newly detected source and switching from newly disconnected source when enabled
CEC Manager™: Power, volume, and muting controls of the connected displays/projectors without any additional control wiring
KD-App Ready: Network scan & detect populates pre-built GUI including connected display/projector controls via CEC Manager™
Ease of Integration: Complete configuration using Key Digital Management Software™ Pro
Power Over HDBaseT: Wall-plate unit powered by Rx/Presentation Switch unit
Installation: Tx unit designed for installation in standard US three-gang box
Signal Extension: 4K/UHD (18G) up to 100m / 328ft. 1080p up to 150m / 492ft
Surround Audio: Support for Dolby® TrueHD, Dolby® Digital Plus, Dolby Atmos®, and DTS-HD Master Audio™
Control System Support: Fully controllable by all TCP/IP and RS-232 supported control systems via open API

Additional Features

HDCP Licensing: Fully licensed and compatible with HDCP 2.2
HDR: More life-like images through a greater range of luminance levels
Deep Color Support: Up to UHD/4K 30Hz 4:4:4/12 bits or 60Hz 4:4:4/8 bit
Full Buffer System™: Manages TMDS re-clocking / signal re-generation, HDCP authentication to source & display, EDID Control handshake, and Hot Plug Detection Voltage
EDID Management: Internal library with 15 internal EDID handshakes including 4K with HDR in addition to native EDID data copied from the Rx display/device
IR Sensor: Wall-plate collects line-of-sight IR from remote(s) without external IR wiring
RS-232: Bi-Directional control to/from Tx and Rx/Presentation Switch unit
