Aurora HDMI/DVI to VGA/YPbPr w/Audio Converter - ASP-HTV

Aurora HDMI/DVI to VGA/YPbPr w/Audio Converter - ASP-HTV

ASP-HTV HDMI/DVI to VGA/Component & Audio Converter offers an easy and instant approach for converting digital HDMI to analog PC video (VGA) and component video (YPbPr) with digital audio (S/PDIF) and analog stereo audio. With this module, YPbPr/VGA based receivers such as LCD monitors or plasma TV can be readily connected to HDMI sources such as DVD players or PS3. In addition, the embedded HDMI / DVI selector facilitates the switch between the HDMI and DVI input sources. This cost effective solution lets you keep using your non-HDMI/DVI display to access HDMI or DVI source, and enjoy high definition digital video and audio.

Benefits:

• HDMI 1.2a & DVI 1.1 compliant


• HDMI video supports up to 1080p


• Support HD (1080i / 720p) component video output


• Support up to UXGA (1600x1200@60) & WUXGA (1920x1200@60) PC graphics output


• Coaxial S/PDIF audio output


• Stereo analog audio output


• Front panel LED indicators and push button


• EDID learning ability

Video Output
Bandwidth
Single-link 165MHz [4.95Gbps]

Resolution
Up to 1080p60, WUXGA [1920x1200@60] & UXGA [1600x1200@60]

Connectors
Type A [19-pin female], DVI-I [29-pin female digital only], HD-15 [15-pin D-sub female], Coaxial socket for S/PDIF digital stereo audio [PCM 48kHz]



Power
Power Supply
5V 2A DC

Power Consumption
6Watts



Physical
Dimensions
5" x 3.9" x 1.1" [128 x 100 x 28mm]

Weight
1.8lbs [795g]
