Aurora 4x4 HDMI® 2.0a Matrix, - ASP-442A

The ASP-442A is an HDMI® 2.0A 4x4 4K 60Hz matrix offering the power and flexibility you need at a cost effective price. Route Ultra High Definition video sources and multi-channel digital audio from any of the HDMI® inputs to the any of the HDMI® outputs at the same time. The front keypad and LCD display are designed for easy operation and quick status of routing. LAN and RS-232 Ports have advanced protocols allowing hot plug detection, signal detection, EDID table loading/recalling, presets, and more. The advanced protocol make the ASP-442A perfect for commercial applications with auto switching, digital signage with device detection, or residential systems with home automation.

• 1x ASP-442A
• 1x 12v Desktop Power Supply
• 2x Rack Mount Ears

• HDMI® 2.0a
• Resolutions up to 4K2K @ 60Hz 4:4:4
• HDR High Dynamic Range
• HDMI® 3D Compliant
• HDCP 2.2 Compliant
• Allows any source to be displayed on multiple displays at the same time
• Allows any HDMI® display to view any HDMI® source at any time
• Supports 7.1 channel digital audio
• Advanced EDID Functions
• Easy installation with rack-mounting
• Front LCD Status Display
