Elite Screens VMAX 2, 170", 1:1, MaxWhite® fabric - VMAX170XWS2
Elite Screens VMAX 2, 170", 1:1, MaxWhite® fabric - VMAX170XWS2Elite Screens VMAX 2, 170", 1:1, MaxWhite® fabric - VMAX170XWS2Elite Screens VMAX 2, 170", 1:1, MaxWhite® fabric - VMAX170XWS2

Elite Screens VMAX 2, 170", 1:1, MaxWhite® fabric - VMAX170XWS2

Part Number: VMAX170XWS2
Our Price: $1,181.00
Availability: Usually ships the same business day
-
+
Free Shipping
This item qualifies for FREE GROUND SHIPPING! Contiguous U.S. only.

Description

This VMAX 2 screen features a 170" diagonal viewing surface. 1:1 aspect ratio is ideal for custom AV and DIY projection applications. Features MaxWhite® projection fabric.

Max White

MaxWhite
MaxWhite Front Projection Material
Gain: 1.1 | View Angle: 180° (90° ± LR)

MaxWhite screen material is the most versatile screen surface for front projection presentations. This material provides the widest possible viewer angles with perfect diffusion uniformity while giving precise definition, image color reproduction and black & white contrast. Screen surface has black-backing to avoid light penetration and can be cleaned safely with mild soap and water. Woven screen material is a multi-layer, cross-array coated with a matte white reflective compound.

Electric Motorized Projection Screen

The VMAX 2 Series is an enhanced electric motorized projector screen for commercial and home theater applications. It has a silent and power-saving synchronous motor. With standard features such as the IR & RF remotes, 12v Trigger and Electronic "Eye" Receiver, the VMAX 2 series also includes Elite Screens GREENGUARD® Certified MaxWhite® and MaxWhite® Fiberglass materials that are ideal for large group presentations.

Screen Material
  • MaxWhite® 1.1 Gain black backed material
  • MaxWhite® FiberGlass backed 1.1 Gain material, models 166" & below
  • 180° wide viewing angle
  • 4K Ultra HD, Active 3D, and HDR Ready
  • Not compatible with Ultra/Short-throw Projectors
  • Standard 4-side black masking borders
  • Matte White material is durable and easy to clean
  • Available in the following range of diagonal sizes:
    • 170" in 1:1 format
    • 100" and 120" in 4:3 format
    • 100" and 166" in 16:9 format
Design and Installation
  • Durable metal casing for wall/ceiling installation
  • Includes wood screws and drywall anchors
  • Bubble leveler included
  • Ships fully assembled with 3-prong power connection ready to plug & play
  • Optional 6" & 12" L brackets – sold separately
Control System
  • Standard Infrared (IR) and Radio Frequency (RF) remote controls
  • Detachable 3-way wall switch
  • Radio Frequency (RF) remote capable of operating from up to 100 feet away without the necessity of line of sight
  • Built-in 5-12 volt trigger input enables Drop/Rise operation to synchronize with the projector's power cycle
  • Low-voltage internal IR/RF receivers
  • CAT5 cable wit RJ-45 connector for easy extension of the 5-12 volt trigger / IR "eye" receiver / 3-way wall switch
  • Optional wireless 5-12 volt trigger, Universal 5-12 volt trigger (for projectors that don't have a trigger output port) and In-wall switch – sold separately
Quality and Reliability
  • Synchronous motor allows silent operation with extended operational longevity and low power consumption
  • Certified by AMX and CRESTRON
  • MaxWhite® FiberGlass: Flame Retardant- Complies with NFPA 701 Standards
  • GREENGUARD® and GREENGUARD® Gold Certified
  • Conforms to ANSI/UL STD. 60950-1
  • Certified to CAN/CSA STD. C22.2
  • 2-year limited warranty, and 3-year warranty for ENR-G – Education, Non-profit, Religious and Government/Military organizations
  • Lifetime Tech Support by Elite Screens Professional Service Team through Email, Phone or Online Form.
