Draper Ultimate Access V Tensioned Recessed Electric Projection Screen

Complete concealment and smooth clean design makes the Ultimate Access V ideal for boardrooms, mid-sized training rooms, universities, or home theaters. During use, a second motor opens the lower panel upward into the case to allow the screen to descend into the room. Retracted, the projection screen completely conceals behind a smooth, lower panel in the ceiling with no exposed screw heads or fasteners. Installation of the case during the initial phase of construction eliminates job site damage allowing for installation of the screen at a later time.

Product Specs

• Case dimensions are 9-7/8" high x 8" deep (25 cm x 20 cm), includes trim flange.
• Built-in controls may increase case length. Mounting brackets may add to case dimensions.
• Maximum image width up to 12' (366 cm) wide, depending on surface selection.
• Image area fully framed with black. Standard 12" (30 cm) black drop at top of viewing area.
• Adjustable or removable hoisting brackets included for easy lifting during installation.
• Sliding brackets on top of case allow for adjustments for mounting. Sliding brackets inside case accommodate different size screens.
• Bottom access panel door is detachable or hangs in place with “T” bracket to provide accessibility for service or maintenance.
• Fully automatic ceiling closure panel provides complete screen concealment. Can be finished by contractor to match ceiling.
• RF welded tabs create a more durable seal eliminating separation and stickiness.
• Quick-connect wiring allows for early installation of the case with the addition of the screen later.
• Includes a 110V three-position switch (standard). Quiet, low voltage motors and 220V options are available.
• Low voltage video interface or other controls can be built into the housing for below ceiling access.
• White case standard, black available upon request.
• Custom sizes available.
• UL Listed.
