Blackmagic Design ATEM Camera Converter - BMD-SWRCONV

Please click on the SPECIFICATIONS tab above or call our sales team at 1-888-686-0551 for more detailed information on this product.

Get everything you need for cameras in live production with a single converter! Connect your camera’s SDI or HDMI outputs for conversion to optical fiber, while your switcher program feed can be fed back via optical fiber for camera monitoring. ATEM Camera Converter includes an internal battery, talkback, tally, and microphone inputs!

Connections

1 x 10 bit SD/HD switchable.

1 x 10 bit SD/HD switchable.

1 x HDMI type A connector.

1 x HDMI type A connector.

1 x 3.5mm stereo connector for talkback microphone. 1 x 3.5mm stereo connector for stereo headphones, compatible with iPhone headsets.

2 x balanced 1/4" TRS connectors (stereo) microphone level in. When connected, replaces audio from SDI In or HDMI In.

1 x single mode SD/HD switchable with LC connector.

1 x single mode SD/HD switchable with LC connector.

4 x single mode camera audio inputs with LC connector. Channels 1 & 2 are camera audio. Channels 15 & 16 are intercom audio.

4 x single mode camera audio outputs with LC connector. Channels 1 & 2 are camera audio. Channels 15 & 16 are intercom audio.

1 x mini-B type USB 2.0 connector for initial setup, firmware updates and Converter Utility software control.

Standards

525i59.94, 625i50, 720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080PsF23.98,1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080p23.98, 1080p24, 1080p25, 1080p29.97,1080p30, 1080p50, 1080p59.94, 1080p60, 2048 x 1080p/23.98, 2048 x 1080p/24, 2048 x 1080p/25,2048 x 1080PsF/23.98, 2048 x 1080PsF/24, 2048 x 1080PsF/25, 2048 x 1556PsF/23.98, 2048 x 1556PsF/24,2048 x 1556PsF/25.

525i59.94, 625i50, 720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080PsF23.98,1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080p23.98, 1080p24, 1080p25, 1080p29.97,1080p30, 1080p50, 1080p59.94, 1080p60.

SMPTE 259M, SMPTE 292M.

Television standard sample rate of 48Khz, 24 bit A/D conversion.

4:2:2

10-bit

REC 601, REC 709

SDI and HDMI are switchable between between standard definitlon and high definition

Software

Converter Utility.

Operating Systems

• Mac OS X 10.9 Mavericks, Mac OS X 10.10 Yosemite or later.
• Windows 7 or Windows 8.

Power Requirements

12V power supply included with international socket adapters for all countries.

What's Included

• ATEM Camera Converter
• Software CD

Warranty

3 Year Limited Manufacturer's Warranty.
Excluding connectors, cables, cooling fans, fiber optic modules, fuses, keyboards and batteries which will be free from defects in materials and workmanship for a period of 12 months from the date of purchase.
